A UNION OF GENESIS 1:1 AND JOHN 1:1. The number 37 is the number upon which this article is based. It is unequivocally the principal number of God, His signature, His confirmation, and the basis of His maths lesson. The number 37 is bi-figurate being both the 2 nd star or hexagram and the 3 rd centred hexagon. This article deals with the 37 th terms of various polygonal numbers and a table. A nonagon or 9-gon is a shape with 9 sides and 9 corners. Regular nonagon. All sides of a regular nonagon are the same length. Each corner is 147. All corners added together equal 6840°. The amount of space a regular nonagon takes up is.

In geometry, a nonagon (/ˈnɒnəɡɒn/) or enneagon (/ˈɛniəɡɒn/) is a nine-sided polygon or 9-gon.

The name nonagon is a prefixhybrid formation, from Latin (nonus, 'ninth' + gonon), used equivalently, attested already in the 16th century in French nonogone and in English from the 17th century. The name enneagon comes from Greekenneagonon (εννεα, 'nine' + γωνον (from γωνία = 'corner')), and is arguably more correct,^[1] though less common than 'nonagon'.

Regular nonagon[edit]

A regular nonagon is represented by Schläfli symbol {9} and has internal angles of 140°. The area of a regular nonagon of side length a is given by

${\displaystyle A=\frac{9}{4}{a}^2\cot \frac{\pi }{9}=(9/2)ar=9r^2\tan (\pi /9)}$

${\displaystyle =(9/2)R^2\sin (2\pi /9)\simeq 6.18182a^2,}$

where the radius r of the inscribed circle of the regular nonagon is

You are confusing your PC's 'special' function keys, which can do all sorts of specific tasks — such as change volume and other media settings, turn wifi off and on, en/disengage Num Lock, and etc. — with the standard F1-F12 function keys, which DO NOT have any specific functions defined for them by default in Windows; that would completely defeat their purpose, in fact. Space pirates and zombies walkthrough. MGW: Independent Game Platform - Video Game News - Video Game Cheats -Game System Requirements -Game Guides - 2012-2020 Magic Game World. Space Pirates And Zombies 2 Cheat Codes. While playing the game, press Alt + F7 to unlock the “Cheats” menu. Related Posts: Plants vs Zombies PS3 Cheats. PC CHEATS & TRAINERS / SPACE PIRATES AND ZOMBIES 2 Space Pirates and Zombies 2 Trainer Our Space Pirates and Zombies 2 +6 trainer is now available for version 1.100 and supports STEAM. These Space Pirates and Zombies 2 cheats are designed to enhance your experience with the game.

${\displaystyle r=(a/2)\cot (\pi /9)}$

and where R is the radius of its circumscribed circle:

${\displaystyle R=\sqrt{(a/2{)}^2+r^2}=r\sec (\pi /9).}$

Construction[edit]

Although a regular nonagon is not constructible with compass and straightedge (as 9 = 3², which is not a product of distinct Fermat primes), there are very old methods of construction that produce very close approximations.^[2]

It can be also constructed using neusis, or by allowing the use of an angle trisector.

The nonagon can be constructed with 36 meccano equal bars. The construction includes 9 equilateral triangles. Bars are disposed in four levels. Physical models are possible selecting correctly the size of the pieces in order bars and bolts don't obstruct anything else.

Approximations[edit]

Approximation I[edit]

Accuracy (linear): 10⁻⁶

The following is an approximate construction of a nonagon using a straightedge and compass.

Example to illustrate the error, when the constructed central angle is 39.99906°:
At a circumscribed circle radius r = 100 m, the absolute error of the 1st side would be approximately 1.6 mm.

Approximation II[edit]

Accuracy (linear): 10⁻¹⁰

• Downsize the angle JMK (also 60°) with four bisections of angle and make a thirds of circular arc MON with an approximate solution between bisections of angle w₃ and w₄.
• Straight auxiliary line g aims over the point O to the point N (virtually a ruler at the points O and N applied), between O and N, therefore no auxiliary line.

Thus, the circular arc MON is freely accessible for the later intersection point R.

${\displaystyle \mathrm{\angle }}$ RMK = 40.0000000052441..°

360° ÷ 9 = 40°

${\displaystyle \mathrm{\angle }}$ RMK - 40° = 5.2..E-9°

Example to illustrate the error:

At a circumscribed circle radius

r = 100,000 km, the absolute error of the 1st side would be approximately 8.6 mm.

See also the calculation (Berechnung, German).

• Nonagon at a given circumscribed circle, animation]]

• Nonagon at a given side length, animation

Symmetry[edit]

The regular enneagon has Dih₉ symmetry, order 18. There are 2 subgroup dihedral symmetries: Dih₃ and Dih₁, and 3 cyclic group symmetries: Z₉, Z₃, and Z₁.

These 6 symmetries can be seen in 6 distinct symmetries on the enneagon. John Conway labels these by a letter and group order.^[4] Full symmetry of the regular form is r18 and no symmetry is labeled a1. The dihedral symmetries are divided depending on whether they pass through vertices (d for diagonal) or edges (p for perpendiculars), and i when reflection lines path through both edges and vertices. Cyclic symmetries in the middle column are labeled as g for their central gyration orders.

Each subgroup symmetry allows one or more degrees of freedom for irregular forms. Only the g9 subgroup has no degrees of freedom but can seen as directed edges.

Tilings[edit]

The regular enneagon can tessellate the euclidean tiling with gaps. These gaps can be filled with regular hexagons and isosceles triangles. In the notation of symmetrohedron this tiling is called H(*;3;*;[2]) with H representing *632 hexagonal symmetry in the plane.

Graphs[edit]

The K₉complete graph is often drawn as a regular enneagon with all 36 edges connected. This graph also represents an orthographic projection of the 9 vertices and 36 edges of the 8-simplex.

Pop culture references[edit]

• They Might Be Giants have a song entitled 'Nonagon' on their children's album Here Come the 123s. It refers to both an attendee at a party at which 'everybody in the party is a many-sided polygon' and a dance they perform at this party.^[5]
• Slipknot's logo is also a version of a nonagon, being a nine-pointed star made of three triangles, referring to the nine members.
• King Gizzard & the Lizard Wizard have an album titled 'Nonagon Infinity', the album art featuring a nonagonal complete graph. The album consists of nine songs and repeats cyclically.

Architecture[edit]

Temples of the Bahá'í Faith, called Bahá'í Houses of Worship, are required to be nonagonal.

The U.S. Steel Tower is an irregular nonagon.

See also[edit]

• Enneagram (nonagram)

References[edit]

1. ^Eric W. Weisstein. 'Nonagon'. > MathWorld--A Wolfram Web Resource. Retrieved 24 October 2018.
2. ^J. L. Berggren, 'Episodes in the Mathematics of Medieval Islam', p. 82 - 85 Springer-Verlag New York, Inc. 1st edition 1986, retrieved on 11 December 2015.
3. ^Ernst Bindel, Helmut von Kügelgen. 'KLASSISCHE PROBLEME DES GRIECHISCHENALTERTUMS IM MATHEMATIKUNTERRICHT DER OBERSTUFE'(PDF). ERZIEHUNGSKUNST. Bund der Freien Waldorfschulen Deutschlands. pp. 234–237.Retrieved on 14 July 2019.
4. ^John H. Conway, Heidi Burgiel, Chaim Goodman-Strauss, (2008) The Symmetries of Things, ISBN978-1-56881-220-5 (Chapter 20, Generalized Schaefli symbols, Types of symmetry of a polygon pp. 275-278)
5. ^TMBW.net

External links[edit]

• Properties of a Nonagon (with interactive animation)
